5754 Aluminum Coil China Suppliers
5754 aluminum coil is Al-Mg alloy, the use of a wide range, especially the construction industry is inseparable from this alloy, is the most promising alloy. Good corrosion resistance, excellent weldability, cold workability is better. Its high strength, especially high anti-fatigue strength, high plasticity and corrosion resistance, good weldability, poor cutting performance, can be polished.
Specification of 5754 Aluminum Coil :
| Grade | 5754 |
| Temper | All available, H1X, H2X, H3X, O, HXXX |
| Coil ID | 75mm, 150mm, 200mm, 300mm, 400mm, 508mm or negotiable |
| Coil OD | Per customer’s request |
| Thickness | 0.20-8.0mm |
| Width | 8-2400mm |
| tolerance | +/-2% |
| Alloy or not | Non-alloy/pure aluminum |
| Standard | JIS, AISI, ASTM, GB, DIN, EN |
| Certification | ISO |
| Surface | Powder coated, anodized polishing, mirror finish, diamond , tread, brushed, wood grain, stucco embossed |
| Property | Anti-corrosion, heat resistant |
| Production process | Cold rolled |
| Application | Storage device, decoration, pressure vessels ,etc |
| Core | Paper core |
| Coil weight | Max.2 tons |
| Origin | China mainland |
| Payment | TT,LC |
| Package | Covered with a layer of plastic film and cardboard, packed on the wooden pallets, bound with iron belt, loaded in the containers. |
| Delivery | 15~30 days |
Chemical Composition of 5754 Aluminum Coil :
| Grade | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Al |
| 5754 | 0.400 | 0.400 | 0.100 | 0.500 | 2.6-3.6 | 0.300 | – | 0.200 | remains |
Performance of 5754 Aluminum Coil :
- Low density, high strength
- Durable, economic and environmental protection, high safety performance
- Anodized surface after treatment
- Arc welding performance is good
- Good forming processability, corrosion resistance, weldability
- Provide China and Switzerland Classification Society certification
Applications of 5754 Aluminum Coil :
Ship plate, aircraft plate welding parts, tankers, oxygen machine tower, ship structure, fuel tank, gasoline and lubricants pipe, flange, high-noise rail noise barriers, tanker tank material, high-grade alloy doors and windows
