5182 Aluminum Coil China Suppliers
5182 aluminum belongs to the Al-Mg-Si alloy, and used widely, especially in the construction industry, it has been recognized as the most promising alloy with good corrosion resistance, weldability, cold processing property, and moderate strength. The Mg and Si are added to 5182, so the welding, spot welding and roll welding properties of 5182 aluminum sheet are pretty good.
Specification of 5182 Aluminum Coil :
| Grade | 5182 |
| Temper | H11,H18,H19,H38,H39,O |
| Coil ID | 75mm, 150mm, 200mm, 300mm, 400mm, 508mm or negotiable |
| Coil OD | Per customer’s request |
| Thickness | 0.20-7.0mm |
| Width | 200-2200mm |
| Production process | Cold rolled |
| Application | Storage device, decoration, pressure vessels ,etc |
| Core | Paper core |
| Coil weight | Max.2 tons |
| Origin | China mainland |
| Payment | TT,LC |
| Package | 1) Packaging Detail:
Plate/coil is placed to the iron or wooden pallet ,wrapped by water-proof craft paper perfectly , then fixed by iron narrow belt well . 2) Port: Qingdao port or other main port in China 3) Container: 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) , loading 18~25 tons . 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) , loading 20~28 tons. |
| Delivery | 15~30 days |
Chemical Composition of 5182 Aluminum Coil :
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Other | Min.A1 |
| 5182 | 0.2 | 0.35 | 0.15 | 0.2-0.5 | 4.0-5.0 | 0.1 | – | 0.25 | 0.1 | 0.05 | Remainder |
Application of 5182 Aluminum Coil :
5182 aluminum sheet does well in processing cans cover, car body panels, operation panel, stiffeners, brackets and other components. It can also used for manufacturing aircraft fuel tanks, fuel lines, and metal sheet parts of transportation vehicles, vessels, instruments, lights bracket and rivets, hardware and shells of electrical appliances.
