5083 Aluminum Coil China Suppliers
The 5083 aluminum alloy is a high – magnesium alloy, which has good strength, corrosion resistance and good cutting ability in non – heat treatment alloy. The anodized surface is beautiful. Good performance of arc welding. The main alloy elements in 5083 alloy are magnesium, with good corrosion resistance and weldability, and moderate strength.
Specification of 5083 Aluminum Coil :
| Grade | 5083 |
| Temper | All available, H1X, H2X, H3X, O, HXXX |
| Coil ID | 75mm, 150mm, 200mm, 300mm, 400mm, 508mm or negotiable |
| Coil OD | Per customer’s request |
| Thickness | 0.20-8.0mm |
| Width | 8-2400mm |
| tolerance | +/-2% |
| Alloy or not | Non-alloy/pure aluminum |
| Standard | JIS, AISI, ASTM, GB, DIN, EN |
| Certification | ISO |
| Surface | Powder coated, anodized polishing, mirror finish, diamond , tread, brushed, wood grain, stucco embossed |
| Property | Anti-corrosion, heat resistant |
| Production process | Cold rolled |
| Application | Storage device, decoration, pressure vessels ,etc |
| Core | Paper core |
| Coil weight | Max.2 tons |
| Origin | China mainland |
| Payment | TT,LC |
| Package | Covered with a layer of plastic film and cardboard, packed on the wooden pallets, bound with iron belt, loaded in the containers. |
| Delivery | 15~30 days |
Chemical Composition of 5083 Aluminum Coil :
| Grade | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Al |
| 5083 | 0.400 | 0.400 | 0.100 | 0.40-1.0 | 4.0-4.9 | 0.05-0.25 | – | 0.250 | remains |
Features of 5083 Aluminum Coil :
- The main ingredient of this series aluminum sheet is magnesium element and the content is between 3% and 5%. It is also called aluminum magnesium alloy.
- With its low density, it features high tensile strength and elongation..
Application of 5083 Aluminum Coil :
Unfired welded pressure vessels, heavy-duty truck/trailer assemblies, marine hulls, superstructures, drilling rigs, missile components, railroad cars
